Gear Pump

Gear Pump Specification

Working Temperature
Up to 150C standard Up to 250C with jacketed models Celsius (oC)

Voltage
415 Volt (v)

Flow Rate
From 1 LPM to 1,000+ LPM (up to 60 m/hr)

Frequency
50 Hertz (HZ)

Features
High Quality

Usage
Industrial

Material
Metal

Color
Blue Paint Coated

Pressure
High Pressure

Gear Pump Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
30 Days

Main Domestic Market
All India

About Gear Pump

The Gear Pump is a high-quality, industrial-grade solution designed for efficient fluid transfer and handling in demanding environments. Equipped with a robust metal construction and coated in durable blue paint, this pump operates seamlessly at 415 volts and a frequency of 50 Hz, ensuring reliable performance. It is tailored for high-pressure applications, functioning effectively across flow rates ranging from 1 LPM to over 1,000 LPM (up to 60 m/hr). Its ability to operate at temperatures up to 150C standard and up to 250C with jacketed models makes it ideal for handling heat-sensitive materials. The pump combines precision engineering with durability for unmatched fluid transfer efficiency in industrial processes.

Parameter	Specification / Options
Pump Type	External Gear Pump (most common) / Internal Gear Pump
Operating Principle	Positive displacement using meshing gears to transfer fluid
Flow Rate Range	From 1 LPM to 1,000+ LPM (up to 60 m3/hr)
Discharge Pressure	Up to 10-15 bar (can go higher with special designs)
Viscosity Handling	10 to 100,000 cP (ideal for oils, resins, syrups, etc.)
Temperature Range	Up to 150 deg C standard Up to 250 deg C with jacketed models
Suction Lift	Up to 5 meters (wet priming)
Self-Priming	Yes
Direction of Rotation	Bi-directional (Reversible flow - optional)
Body Material (MOC)	- Cast Iron (CI) - for oils, fuels, solvents - SS304 / SS316 - for chemicals & food-grade - Bronze (optional)
Gear Material	EN8, SS304, SS316, Bronze, Hardened steel
Shaft Sealing	Gland packed / Mechanical Seal / Lip Seal
Mounting Type	Baseplate / Bare pump / Close-coupled / Motor mounted
Drive Options	Electric motor (standard), VFD, Flameproof motor (optional)
Port Size	1/2" to 4" (BSP / NPT / Flanged / Tri-clamp)

FAQs of Gear Pump:

Q: What working temperatures can the Gear Pump handle?

A: The Gear Pump operates at temperatures up to 150C under standard conditions and up to 250C when using jacketed models.

Q: What flow rate does the Gear Pump support?

A: The Gear Pump supports fluid flow rates ranging from 1 LPM to over 1000 LPM (up to 60 m/hr).

Q: Can this pump handle high-pressure applications?

A: Yes, the Gear Pump is specifically designed for high-pressure industrial applications.

Q: What is the pumps power specification?

A: The Gear Pump requires a voltage of 415 volts and operates at a frequency of 50 Hz.

Q: Is the pumps material built to endure industrial environments?

A: Absolutely, the Gear Pump is constructed from high-quality metal and coated with durable blue paint, ensuring longevity and performance in challenging industrial conditions.
